FEATURE: Amp Glossary
Balanced connector: A 3-conductor connector which carries a signal over 3 wires, commonly used in microphones but also in some guitar and bass amp recording outputs. Also called XLR or Cannon.
Bright switch: Increases the treble of an amp, either by adding extra treble or by shifting the range of frequencies the amp’s treble control operates in. Can have a similar effect to a Presence control, but is not variable.
Cascading: Wiring preamp stages in series for more gain. Common in Crate amps, where the Sequential Cascading Gain feature makes each potentiometer affects the one after it for greater tonal control.
Channel: Independent sound sections allowing different tones. Commonly clean and distorted, but more often clean, crunch and lead in modern amps.
Channel switching: Changing from one amp channel to another, achieved either by a switch on the amp itself, a foot switch, or MIDI. Some units allow you to combine effect units with particular amp channels to be recalled at the tap of a foot.
Class A: Circuit in which the device is always conducting electricity to some extent, drawing power even if there is no signal at all.
Class B: Circuit which amplifies only half of the input wave cycle. Circuit switches off the amplifying element half the time for greater efficiency, but with a large amount of distortion.
Class A/B: Circuit in which the signal mostly stays in the Class A region, but with efficiency benefits of Class B, without much of the associated crossover distortion.
Combo: An amplifier which contains its own speaker, instead of requiring a separate speaker box.
Compression: Evens out a signal’s dynamic range by capping the volume level while simultaneously increasing the volume of quiet signals. Can be achieved with a pedal, built into an amp, or applied in the recording studio. Valve amps also offer a type of compression when cranked.
Crossover distortion: Distortion created when the top and bottom devices in a push-pull amplifier circuit are amplified at slightly different times.
dB (decibel): A measure of volume.
Depth (1): An amp control which increases the bass frequency response. More commonly found on modern amps built for metal, or for baritone or 7 string guitars.
Depth (2): A control for setting the character of effects such as chorus, phaser or flanger, which may be built into an amp.
Distortion: Technically, amplifying a signal until it’s louder than the circuit can take. Originally a problem which engineers tried to design out of amps, but now appreciated as the greatest thing ever invented.
Dynamic range: The relationship between the minimum and maximum signal level. Can describe how an amp responds to hard and soft pick attack, volume swells, etc.
Effect chain: A series of sound effect devices wired one after the other.
Effect loop (Series): A point in an amplifier’s circuit where a single effect or an effect chain can be inserted into the signal. This usually occurs after the preamp but before the power amp, allowing the effects to add ambience or colour to the main guitar tone.
Effect loop (Parallel): An effects loop in which the signal is split after the preamp, so the unaffected sound goes to the power amp but the effect loop runs alongside, allowing effects to be added ‘around’ the main tone. The original unaffected tone is heard at the same time as the effected tone. Usually parallel effect loops have a control for blending the level of the loop. Some amps feature both series and parallel effect loops.
EQ: In a nutshell, tone controls (at least in the context of amps). This can refer to knobs or sliders.
Extension speaker: A speaker cabinet which can be added to an amplifier. Technically it can refer to any cabinet plugged into an amp, but is more commonly used to refer to adding an extra speaker cabinet to a combo amp.
Jack: The hole a plug plugs into. Or some guy who jumps out of a box.
Feedback: That squealy sound when a microphone or guitar pickup re-processes the signal from a speaker broadcasting it. Some feedback is ugly and people spend thousands of dollars trying to eliminate it from acoustic guitars and PA systems. Other feedback is glorious and controllable and should be encouraged. Check out the intro to Joe Satriani’s “Flying In A Blue Dream” for controlled feedback in a musical context.
FET (field-effect transistor): A solid state device which is more stable than standard transistors, making it easier to achieve consistent sonic results compared to vintage transistors, which varied greatly.
FET distortion: A more valve-like distortion than can be achieved by other types of transistors. Popular in pedals and solid state late 80s amps. – When overdriven, a FET exhibits distortion qualities more like those produced by a tube than most other types of transistors.
FET switching: A FET circuit which is used to turn on effects in amps or pedals, or to switch amp channels.
Footswitch (latching): A switch for turning an effect on or off, or for switching amp channels. Press it once and the effect goes on. Press it again and the effect goes off.
Footswitch (momentary): A different kind of switch which can work in the same way as a latching switch, or which can be tapped multiple times to set a delay or modulation rate, or to kick in effects only when the pedal is being pressed down.
Gain: Another term that has many meanings, but in this case usually means ‘amount of distortion.’
Gain boost: Usually an extra gain stage that can be turned on and off with a footswitch, especially for solos.
Headroom: The difference between peak tone and peak volume. For instance, ‘Clean headroom’ refers to how loud a clean sound can get before it distorts.
Impedance: Measured in ohms, the total opposition to the flow of alternating current in a circuit.
Master volume: A global volume control for setting the overall volume of an amp. There may be individual channel volumes too for setting the ratio between rhythm volume and solo volume.
Ohm: The unit used to measure electrical resistance or impedance.
Power amp: The part of an amp which drives the speakers. Can be part of a head or combo, or a separate unit for use in a rack system.
Power amp in: Can be another name for an effect loop return. Can allow a head or combo’s power amp to be driven by an external preamp.
Power attenuator: A device for absorbing some of the speaker load so an amp can be cranked for best tone without being too loud.
Preamp: The part of an amp which contains the gain control and tone controls. The main voice of the amp.
Presence: A control which adds additional treble to the circuit.
Solid state: In this context, refers to diodes and transistors instead of valves.
Wattage: How much power an amp handles.
Common valve types:
12AX7: Preamp valve. Dual triode valve with high voltage gain. Used in most preamps, and some overdrive and distortion pedals. Also called ECC83.
6L6: Power amp valve. Pentode valve with quick response, solid bass, high headroom. Common in Fender, Mesa Boogie amps.
EL34: Power amp valve. Warm response, musical distortion characteristics. Common in Marshall amps.
EL84: Power amp valve. Treble-heavy, clear tones when overdriven. Common in Vox AC-30 amps.
KT88: Power amp valve. Beam tetrode valve designed specifically for audio amplifications. In Marshall Kerry King signature model.
KT66: Power amp valve. Good alternative to 6L6 due to higher overload tolerance. In Marshall Vintage Modern series.
